In this pilot program, the opportunity for non-intrusive inspection (NII) was brought about, at least in part, by the widespread implementation of risk based inspection (RBI) at the facility.

Previous major outages were driven by prescriptive requirements for internal inspections of pressure vessels every four years (for most vessels). After risk based inspection was implemented, the internal inspection intervals were extended for many vessels, but there were a few remaining items still requiring internal inspection every four years. In particular, flare drums required shorter inspection intervals due to the greater variability in their service conditions and the modeled corrosion rates. Therefore the driver for non-intrusive inspection was to avoid costly plant shutdowns which were otherwise driven by a very few, or in some cases, a single vessel. (Other ways to manage vessel corrosion is discussed in Introduction to Managing Internal Corrosion in Process Vessels.) This made non-intrusive inspection a cost-effective option.

What is a Non-intrusive Inspection?

The commonly accepted definition of non-intrusive inspection is an inspection to determine the internal condition of the equipment without having to open the equipment.

In practical terms the process uses conventional non-destructive testing with a detailed and planned scope, aiming to achieve an understanding of the internal condition that is at least equivalent to an internal inspection. The decision was made early on to employ a specialist inspection provider, with experience in scoping and execution of non-intrusive inspection.

In this pilot study, the main non-destructive methods used were ultrasonic testing (UT), including ultrasonic corrosion mapping, radiographic testing (RT) and time of flight diffraction ultrasonics (TOFD). The time of flight technique was used to inspect for weld defects. The actual techniques used and the coverage required, for each particular inspection, would be a function of the identified degradation mechanisms for that equipment.

Local Factors Favoring Non-intrusive Inspection

  • An extensive and detailed inspection history, extending for almost 30 years
  • An established risk based inspection program, with well-understood corrosion rate models
  • The dominance of CO2 corrosion as a degradation mechanism, where nondestructive testing methods are well established, with a high probability of detection of defects and underlying corrosion problems
  • Existing corrosion models that indicated that corrosion was either slow or not anticipated, and hence there was a high probability that inspection would serve to validate the predictions, rather than one which identified a need for remedial actions

Vessel Selection

Vessels were initially short listed on the basis of the next due inspection date. Eight vessels were selected, as shown in Table 1.

Table 1. Vessels selected for non-intrusive inspection.

From the table, it can be seen that the judicious application of non-intrusive inspection can avoid or defer major outages that would otherwise have significant impacts on production. An important driver in the field areas is the issue of the safety of confined space inspections, as a confined space entry in a remote site requires additional rescue personnel on standby.

Planning for the Non-intrusive Inspection

The planning required for this type of inspection commenced well before the inspection date; the minimum practical planning time was about three months. Planning was in two stages: a desktop review and an onsite evaluation. The desktop review included a review of the inspection histories and the existing risk based inspection model outputs.

The on-site evaluation was a job walk through. This included identifying the physical access, where scaffolding or rope access was required and where insulation needed to be removed. At the end of the on-site evaluation, a written inspection scope was produced that included a formal evaluation of whether a non-intrusive inspection was feasible for the vessel. (Read about other Tips for Success in Conducting External Corrosion Direct Assessments.)

Execution of the Inspection

Advance preparations included scaffolding and the mobilizing of equipment and technicians to the site. A combination of rope and scaffold access was used for the onsite inspections. Scaffolds were completed at least two weeks prior to the start of work.

Figure 1 and 2. Scaffolding and rope access for inspections.

Each of the specialist inspection technicians were paired with an onsite technician. This not only leveraged the advanced non-destructive testing skills, but also expedited the start of the work by including personnel already familiar with the site. An additional technician was supplied to the site for the purposes of data collation for forwarding to the engineering team. This allowed for timely review of the data collected by offsite engineers, so that anomalies could be identified and additional testing expedited, while access was available and the equipment and technicians were still on site.

Selected photographs from the inspections are shown in Figures 1 – 4.

Figure 3 and 4. inspection of flare drum and welding using TOFD.

Project Results

In all cases the required inspection interval was achieved. As expected, no immediate concerns were noted from the inspections; this meant that no intrusive inspection activities were required before the next inspection. Cost savings were mostly attributed to delay of outages and in one case delaying a total plant outage. In terms of direct inspection costs, the non-intrusive inspection was about twice that of conventional intrusive visual inspections, for a simple vessel. For a reasonably large vessel of simple construction (such as a flare drum), the duration of the work was about ten shifts (of ten hours each), for a team of two technicians.
