Third Party Long-Term Testing: CUI & Thermal Results

By Ames Kulprathipanja
Published: May 11, 2017 | Last updated: November 16, 2018
Key Takeaways

See the results of an independent research and development organization that recently designed, built and tested fully insulated assemblies protected by leading thin blanket insulations for corrosion under insulation and thermal stability.

Advertisement

Industry leaders continually strive to explore the best methods to provide information to the industrial market. Recently, an independent research and development organization designed, built and tested fully insulated assemblies for corrosion under insulation (CUI) and thermal stability in order to understand how thin blanket insulation performs in “real world” installation and environmental conditions. (For more about CUI, read Corrosion Under Insulation: The Challenge and Need for Insulation.) As part of the testing, the assemblies were exposed to harsh environmental conditions to accelerate corrosion and promote system aging. At the conclusion of the testing, the third-party agency analyzed the results, and we compared them to laboratory data based on ASTM specifications.

The use of a third-party testing agency provides a number of benefits, including consultation and unbiased direction when designing and conducting the tests, as well as objective review and conclusions. This is why this new test method that studies the long-term effects of highly corrosive environments on insulated assemblies is, in our view, a comprehensive look at conditions that reflect “real world” performance.

Advertisement

Test Method

The two competitive, thin blanket insulations examined in this study were a microporous blanket and a silica aerogel blanket insulation. During the testing, two layers of the microporous blanket were wrapped around 2” carbon steel pipes and secured with metal cladding. The silica aerogel was also applied in the same configuration, and each insulated assembly was then exposed to one of the following different environmental conditions:

  • The first condition maintained the pipe temperatures at 45°F (7.2°C) throughout the test, periodically submerging the samples in up to 1,500 ppm chloride solutions, so that the assembly remained wet for the entire duration of the test. These conditions were sustained for a total of 6 months.
  • The second condition periodically immersed the two assemblies in solutions with up to 1,500 ppm chloride. Throughout the test, the pipe temperatures were cycled between ambient and 600°F (315°C), causing “boiling” conditions for 18 hours each week for 6 months.

Results for Conditions One and Two: Corrosion under Insulation

For each of the four test protocols (two insulations in two different environmental conditions), corrosion rates and depths were calculated using an electrochemical method (Table 1), ultrasonic technique, and an optical microscope. The measurements were compared to results from laboratory ASTM tests, using the same two insulation materials on carbon steel. The conclusions from the third-party test agency’s report provide support that ASTM C665 and C1617 test methods currently being used by the industrial industry are a good representation of “real world” conditions. (For more information about test methods, see Q&A: David Shong on the New CUI Test Method ASTM C1617.) The conclusions include the following:

  • At constant low temperatures (45°F conditions), the microporous blanket and the silica aerogel blanket have similar corrosion rates and depths.
  • At high-temperature cycling conditions (between ambient and 600°F), the microporous blanket has lower corrosion rates and depths compared to the silica aerogel blanket.
  • Deep, localized pitting is more significant in high-temperature conditions with the silica aerogel blanket than it is with the microporous blanket.

Third-Party Long-Term Testing: CUI & Thermal Results

Advertisement

Table 1: Mean corrosion depths measured (μm) by electrochemical methods after high-temperature cycling conditions.


Advertisement

Third-Party Long-Term Testing: CUI & Thermal Results

Figure 1: Optical cross-section of a carbon steel surface under the aerogel blanket insulation after high-temperature cycling conditions, showing deep, localized pitting. Deep, localized pitting is more concerning than uniform shallow pits.

Results for Condition Two: Thermal Stability

For the two insulation assemblies that were cycled to 600°F (315°C), the surface temperatures were recorded when the assemblies were dry (not submerged in water) at different times during the test (Table 2). The data show significant differences in thermal performance between the two blankets over time. Temperatures based on NAIMA 3E Plus® software for both insulation materials before and after thermal shift (change in thermal conductivity after exposure to high process temperatures) also show differences in the expected thermal performance. Thermal conductivities based on ASTM C335 (pipe geometry) were used for the modeling calculations (Figure 2).

Third-Party Long-Term Testing: CUI & Thermal Results

Table 2: External metal sheathing temperatures after repeated wet/dry and high-temperature cycles. NAIMA 3E Plus software modeling values before and after thermal shift are shown for comparison.


Third-Party Long-Term Testing: CUI & Thermal Results

Figure 2: Thermal conductivity values tested via ASTM C335 before (1st cycle) and after (2nd cycle) thermal shift. Note the thermal conductivity values for InsulThin HT do not vary between the 1st and 2nd cycles.

The most interesting observations based on the third-party data are the following:

  • At 600°F (315°C) process temperature, the microporous blanket performs as expected and has better thermal performance than the silica aerogel blanket – both initially and after 6 months of wet/dry and high-temperature cycling.
  • The silica aerogel blanket has a higher degree of thermal degradation when compared to InsulThin HT after 3 and 6 months of wet/dry, high-temperature cycling conditions.
  • A thermal degradation of the silica aerogel blanket has been demonstrated in “real world” conditions by the third-party agency testing. Modeling calculations capture the initial thermal shift, but not the longer-term thermal degradation that may be due to high-temperatures and/or exposure to water.

Conclusions

Understanding how “real world” or accelerated conditions may affect insulation test assemblies provides end users with critical information when specifying different materials. The results from the third party testing just described are relevant when designing insulation thicknesses, predicting system longevity, and calculating labor and material costs. Depending on the requirements of the application and the environmental conditions of a project, additional insulation material may be required or the system may need to be repaired more often than planned. The new, third-party data provide an independent and comprehensive perspective when choosing materials that can significantly impact system performance and safety.

Share This Article

  • Facebook
  • LinkedIn
  • Twitter
Advertisement

Written by Ames Kulprathipanja | New Product Development & Innovation Leader, Johns Manville

Ames Kulprathipanja

Ames Kulprathipanja is the Innovation Leader for the Insulation Systems business unit of Johns Manville as well as the Technology Leader for the Industrial Insulations Group. He is responsible for understanding the emerging needs of owners, engineers, and contractors and developing new products for the insulation market. He also leads the technology group for industrial products including technical service and core product support. Ames has spent the majority of his professional career in the residential, commercial, OEM, and industrial insulation industry. Ames has a doctorate in chemical engineering from the University of Colorado-Boulder and worked on various energy technologies including thermal management of complete fuel cell and gas-to-liquid fuel systems before joining Johns Manville.
